Stand Up Pouch Mini Doypack Machine

1.Interlock system.

2.Liquid, powder,granule was available.

3.Design for preformed bag type sealing.

4.Small occupied area becautiful sealing.

Package: wooden case ( free fumigation)





1.Machine introduction:
 Mini doy pack machine was design for user which require a small output, small occuiped area requirement. Using in the preformed bag type like gusset bag, stand up pouch, zipper bag etc. Additional function like air inflation, date printer, material flap, vacuum was available for this machine. working with other filling system like auger filler, liquid pump, volumetric cup, weigher it can be using for pack granule, powder and liquid material.


A. Z type elevator: It is using to help user achieve product automatic feeding and stopping when packing machine need.

B. Multi-head weigher: using to automatic weighting and filling the product, very accurate,the weigher's computer determines the weight of product in each individual weigh hopper and identifies which combination contains the weight closest to the target weight.Then opens all the hoppers of this combination and the product falls, via a discharge chute, into a bagmaker or, alternatively, into a distribution system which places the product.

C. Platform: Using to support weigher and easy for operator to cleaning and inspecting when real production.

D. Zipper bag openner: control by air cylinder, using to open zipper

E. Finished products conveyor: it is using to help user receive the product when after package and send into next process.

2. Features:
- Rigid SUS304 machine frame and contacting parts
- Workable on various pouch type;
- Workalone or integrated with weight filler and conveyors
- No Bag no dump;
- User's friendly HMI;
- Changable bag size;
- Interlock

3. Technical parameter:

Sachet type

Zipper bag, stand up zipper bag
Pillow bag

Sachet size range

Max.Size

100(W)×100mm(L)

Min.Size

300mm(W)×300mm(L)

Filling weight range

≤Customized

Packing speed

5-15 bags/min
(depending on bag size and filling weight)

Electricity  Power

1.5KW

Power Electricity

220V /380V,  50 / 60Hz

Machine Dimension(L×W×H)

1630mm x750mm x450mm

Weight

120KG


4. Machine detail display:


5. Customized solution:


5.Bag sample:

6. Machine package:


7.Machine video on youtube:

 https://youtu.be/5IZl5tulFhY (Powder package example)

https://youtu.be/E4pnDMLXrco (Grain package example)

 https://youtu.be/KV70Nx1BeK0 (Liquid package example)

8. Machine real project cases:
http://www.packhomegroup.com/en/project-case_l146_1.html

For better offer our suggestion and prepare quotation, hope we can know below info:

A. Your bag size

B. Your bag picture

C. Packing weight

D. Packing speed requirement

E. Exactly product need to packed
